HB solar powered wireless signal to wired output transceiver

It converts HB brand wireless solar powered active beams or grating signal to wired signal output for exist host.
Main functions and features:
1.It enables the exist alarm system to add perimeter protection detectors easy.
2.DC12V power supply is required from the third party alarm host or other way.
3.It has 8 defense zones. Each zone learns maximum 6 detectors codes.

Specification:
1.Operating voltage:12V~14V DC
2.Operating current:100mA ~150mA
3.Operating temperature:-30℃~70℃
4.Wireless distance:100~300m(depending on power supply and operating condition)

Total 9 indicators,1 RUN light and 8 zone Lights.
How to connect the detectors
1. Open the enclosure of the adapter,and connect the power cables
(If work normally,the Run light blink)
2. Set the DIP switch to connect the detectors;there are 8 DIP switches corresponding 8 zones;
For example:connect the detectors to zone 1
Make the DIP switch 1 to ON direction,and the indicator of zone 1 light on,and”Run”light
off.(means the Adapter is on learning mode)
Trigger the detector,if “Run” blink,connect successfully(each zone can connect 6 pieces
detectors at most).
Make the DIP switch 1 to figure direction,and the indicator of zone 1 light off,and”Run”light
on.(means the Adapter exit the learning mode)
3. If work normally,the light of zone 1 will on for 30 seconds while you trigger the detector(it
means the output of zone 1 will keep 30 seconds)
4. Connect the detectors to other zones by the same way.
How to delete the detectors
1. Power on the adapter,and “Run”light blink
2. Set the DIP switch to delete the detectors(for example:delete the detector of zone 1)
Make the DIP switch 1 to ON direction,and the light of zone1 on,”Run”light off.
3. Delete all the detectors--Press”Delete Key”2 seconds,the light of zone 1 blink.
4. Delete detector of other zones by the same way
