New burglar alarm, access control and fire alarm equipment

Within 100 meters high sensitivity wireless RF remote. Wireless remote control - 4-key wireless remote control - Novelty design, comfortable to take with you and can be taken as decorations - High sensitivity within 100 meters A.4 independent function keys B.For fast arm/disarm,easy and convenient,emergency call,safe and covert. C.Scientific address code with millions of combination, which enable all the remote controller to be exclusive one,without permitting,it is impossible to copy our wireless products. E.Low consumption for transmitting,indication for signal output visible. F.Compatible with all our 433/868MHz wireless products. Model number: PB-422R Using range: ≤100m( in the open place) When the remote control distance is insufficient, please hang the remote control key ring vertically and press the remote control button. Frequency: 433/868MHz Options: ASK/FSK (depends alarm panel type) Working voltage: 3V (1*CR2450 button battery) uiescent current: ≤1μA Working current: ≤15mA Prompt: The LED light is red when transmitting. Working environment: -10℃-60℃(14℉-140℉) Color: white

Model：HA-IIGW Brand: Focus Manufacturer: Meiantech WiFi+2G/4G Home Alarm +App Control your home security from anywhere Color screen text Menu, easy to programme Tempered glass touch Auto Connect to our Cloud server after power on, free Cloud service all over the world Push notification to your smartphone User remote control via SMS, App or Web GUI,Simple professional-level installation. ·Online firmware upgrade ·Programmable wired outputs. Item No.: HA-IIGW Dimensions 200*140*15MM Housing Materials ABS Plastic+Tempered Glass Surface Installation Location Indoor Use Wall Mounted LCD Display Graphic display, status light Menu Voice Guidance YES Kit Weight 1.20KG Kit Accessories Included 1*Wireless PIR Detector 1*Wireless Door Sensor 2*Wireless Remote Controller 2*RFID tags ASK wireless communication, please shop ASK detectors and accessory. Installation manual can be downloaded at https://www.vedard.com/forum/download/file.php?id=153 System Network 2G/4G WIFI(2.4G) Number Of Users 16 Number Of Wired Zones 0 Number Of Bus Zones NO Number Of Wireless Remotes Or Wireless Keypad Controls: 8 Number Of Wired Keypad 0 Number Of Wireless Zones 64 Number Of Voice Phones 4 Number Of Wireless Doorbell 1 Number Of Wireless Switch 16CH Number Of Wireless Siren Dual Way Siren *1 One Way Siren: No Limited Outputs NO 2G/4G Antenna Internal 2G/4G Antenna Event Log Inquiry 512 Radio Frequency 433MHz or 868MHz Intergrated Siren YES(85Db@1M) Backup Battery Type 12V DC, 7AH Lead Acid Battery Max Receiving Range 150M Max Sending Range 100M Power Supply Unit 5V/2A Protocols Ademco Contact ID Tamper Monitoring YES Mobile Client (APP): search for ST-Panel WebIE YES Meian CMS Server: wode110.com Tel-Line CMS 2 CMS Certifications CE/FCC/ROHS

Focus brand Meian tech manufacturer home security system new technology detector. Dual way communication with alarm panel. That means the detector can send and receive signal. So its status can be queried. MC-575R is wireless digital PIR intrusion detector with pet immunity, it adopts DMT and digit micro processing control, passive PIR with cylindrical FRESNEL lens and dual passive PIR detector technology, it improves energy receiving effectively, higher sensitivity, free of false alarm. By using advanced patented software. It can detect difference between the real intruder and other interference factors which may result in false alarm. Pulse counting can be adjusted, and use more for various indoor applications, capability much over than other general PIR detector, built-in big capacity CR123A 3.0V lit. ◎ Anti-white light with spherical lens and sealed optical design； ◎ Low power consumption, built-in big capacity batteries； ◎ Detection distance：12m@25℃ ◎ Detection angle：110° 1.adpots self-designed MASK chip with DMT technology 2.reliable detection performance with dual passive PIR technology 3.excellent false alarm prevention with look-down window to avoid blind corner 4.wireless detection distance: 12m@25°C / detection angle: 110° 5.wireless emitting distance is 120~150 meter (in open area) 6.pet immunity under 25kgs 7.wireless emitting frequency is 433MHz / 868MHz 8.working voltage is 3.0V DC 9.Anti-EMI >30V/m (30MHz~1GHz) / Anti-White Light >8000LUX 10.installation height 1.8~2.4 meter (6~8 feet) / single-sided corner mount at 45°to wall 11.consumption current is 9uA(static)/20mA(alarm) 12.alarm indication is LED light flash for 2seconds 13.operation temperature is -10°C to +50°C (14°F to 122°F) 14.storage temperature is -20°C to +60°C (-4°F to 140°F) 15.demision:78*51.5*60.5mm ASK or FSK wireless communication can be optional depends on using alarm panel. For example, ST-VGT， ST-IIIB, FC-300, MA-II, MA-IV etc. most alarm panels are ASK wireless communication. HIFI-Alarm-3200, EAVS-2509, FORTUNE-I/III are FSK wireless communication. Shop same brand wireless compatible devices at https://vedardalarm.com/focus-security-m-2

Professional security alarm Focus brand and wireless compatible (ASK or FSK communication can be choosed according to alarm panel) Most alarm panels are ASK communication such as ST-IIIB, FC-300, ST-VGT, ST-VB, HA-VGW, HA-IIGW, ST-IIIGW. Some models are FSK wireless communication such as EAVS-2506, HIFI-NVR-3200, FORTUNE-IIIS. If you are not clear, please contact us. MC-565R is new designed with mini elegant appearance and improvement intrusion detection technology such as 25kg PET immunity, free false alarm, 2 years battery working life. Pulse counting can be adjusted according to environment and season. It is installed on the wall in indoor such as living room, porch. Function of dual Way Communcation to the alarm Panel enables the sensor can be inquired by the alarm panel and avoid missing or fault without knowing. Specification of the motion sensor: 1. Anti-white light with spherical lens and sealed optical design 2. Adpots self-designed MASK chip with DMT technology 3. Detection distance: 9m@25°C / Detection angle: 110° 4. Pet Immunity under 25kgs 5. Wireless Emitting Frequency is 433MHz / 868MHz / 6. Anti-EMI >30V/m(30MHz~1GHz) / Anti-white Light >8000LUX 7. Consumption Current is 9uA(static)/20mA(alarm) 8. Dimension: 91 x 60 x 48mm Note: It can only work with same brand Focus alarm panel, remote control for wireless compatibility. Choose same brand alarm system at https://vedardalarm.com/focus-security-m-2

HiFi Music + Security Alarm NVR +Alarm HDMI 5 in 1 Bluetooth, 4G, TCP/IP, Burglar Alarm, NVR, HiFi Music, Smart Home Control New integrated central monitoring iot system WIFI+GPRS or WIFI+4G network Video function: Video input: 4*IPC1080P Synchronous playback: 4*IPC1080P Video compress mode: H.265 Video output: 1 line HDMI, 1 line VGA output Transmission mode: Support WIFI relay forwarding function system performance: Preview/video/playback/backup/network monitoring Image motion detection: 396 (22×18) detection areas can be set per screen; Multiple levels of sensitivity can be set, adjustable from 1 to 6 levels Double identification of moving image alarm and probe space intrusion alarm Support mobile APP video monitoring, as well as PTZ and home appliance control Support P2P/IE control/platform /Onvif protocol Wifi connection support (meian wifi camera only) Support for routing (router 4G only) Alarm Function: Voice intercom: 1 line two-way voice intercom SMS: support sms alarm, arm/disarm E-mail: Support E-mail receiving of alarm information Support IE remote control Alarm Receiving telephone: 2 CMS phone, 4 user alarm phone, 2 free arm/disarm phone CMS protocol: SIA-2013, meian protocol, Contact ID Defense areas manage: support 8 independent arm/disarm areas arm/disarm timer: support 4 groups of arm/disarm timers Support tamper-resistant Network protocol: Static IP, DHCP (automatic IP address acquisition) network interface: 1 RJ45 10M/100M adaptive 1 UIM card slot, 1 SMA antenna interface, support GPRS/4G USB port 2个: 1个USB2.0，1个USB1.1 System capacity: 32 single bus +96 wireless devices (including intelligent electrical control) Arm/disarm method: Whole arm/disarm, 8 defense area arm/disarm, independent arm/disarm GSM communication: SMS arm/disarm, GPRS network communication 4G communication: Support video upload, 4G 2-way communication, network remote operation and control IP communication: IE programming, remote upgrade, remote control, network alarm Special functions: voice prompt, 2-way intercom, scene monitoring, timer arm/disarm Expanded functions: relay output linkage, program output Wireless system form: FSK wireless system HIFI Function: Audio input: 1 line audio input, PS/2 interface Audio format: WMA, APE, FLAC, AAC, DTS, MP3 Audio source: AUX, Bluetooth, USB, SD, FM, Internet Sound effect：3D stereo, HiFi Site，Mega bass，Pure vocals Voice frequency range: 30Hz-22000Hz Output power: 30W+30W Support alarm linkage voice delivery Keyboard bus 1 RS485 half duplex Support 8 pcs Remote controller, Maximum 100m transmission distance at open area Support maximum 8 wired or wireless keypad Support 16 lines electrical switch control Frequency: FSK 433/868MHz 1 pc 2.5inch SATA hard disk interface, Maximum 4T Built-in battery: 7.4VDC/4Ah Power supply: 110-240VAC 50/60Hz Working environment: -10℃~+55℃，85%@30℃ Optional accessories: (Need to shop FSK communication accessories) HA-8501 WIFI (1080) 1080P WIFI security camera MC-565R（FSK) Wireless motion sensor MD-211R（FSK) Wireless door magnetic contact PB-453R（FSK) Wireless remote controller

Introduction:HA-8403 is integrating the traditional camera and network video server embedded into an digital monitoring system. Based on an embedded Linux Operation system. And adopts Hi3518C hardware platform with high efficient and low volume. high performance, good stability and reliability. With DHCP Way, P2P Cloud Store, Alarm Security Functions. It can work with ip alarm system such as ST-VGT which supports 32 IP Cameras. 32 Wireless Alarm Devices (door sensor, remotes, pir motion detectors......) All Alarm devices can bind each 32 IPCams to alarm. Users can receive the alarming from app, auto recording the video from app after alarming. Freely to check all the alarming events recording, even from TF card. Operation system: Embedded Linux User interface: IE browser, CMS PC client, phone application Video format: mainstream 720P/D1 25fps, Sub-stream D1/CIF 25fps Network interface: 10M/100M adaptive network interface Storage interface: TF card,support max 128G(1st time, please format TF card on IE browser interface).Use a hex screwdriver to open the cover to see the TF card slot. Image sensor: Crystal phase H62,100W (1280*720) Power: DC 12V/1A Specification: Resolution: 2MP(1920*1080) image compression: H.265 storage mode:
