Outdoor Siren strobe for alert of driveway intrusion detection system.
The package is used for house or business perimeter security.
It is newest technology wireless solar powered beams system and solar-powered siren strobe.
Leading package includes 1x 3 beams with LCD calibrator solar-powered infrared detector and 1 pc siren strobe solar-powered outdoor installation with 2 pcs remote controller.
One siren strobe can equip with maximum 32 wireless beams and remote controllers.
Details of driveway intrusion alert neighbor and police notice security system
Wireless beams detector updated with LCD calibrator and electricy power supply and battery rechargeable power jack. Infrared Distance 120m, Wireless emitting distance 1km
Contact us if you have any question. Shopping guide at
how to shop alarm
Specification of the solar powered wireless beams detector:
Infrared Distance: 120m
Wireless Transmitting Distance: 800m
Wireless Transmitting Frequency: FM: 433MHz
Maximum alarm times in 24 hours: Not more than 50times.
Battery Capacity: 500mAh (Transmitting terminal), 1000mAh (Receiving Terminal)
Working environment temperature range: -30C~70C
Number of infrared beams: 3 beams
Operating Voltage: 3.3V
Static Operating Current: Transmitting terminal<=0.5mA, Receiving terminal<=0.5mA
Infrared light frequency: Secondary moudulation & encoding based on 38KHz
Infrared Light wavelength: 940nm+/-20nm
Solar electric panel output current: >=2mA at light intensity of 1800LX (note: the outdoor light intensity in cloudy or rainly days is about 2000LX)
Dimension of product: 340mm*50mm*84mm of Receiving terminal, 340mm*50mm*45mm of transmitting terminal
Precautions:
1.Never install the infrared beams at an inclined angle.
2. Make sure that there is no obstacle between the transmitting terminal and the receiving terminal.
3. Use multiple infrared beams for long distance to avoid mutual interference among beams.
4. Keep the in-frared light hole-posed to direct sunlight.
5. The high-voltage tower and the signal tower may influence wireless transmission distance.
6. Never install this infrared beams near door access systems, passages, areas prone to trigger an alarm or areas which could trigger an alarm more than 50 times per 24 hours.
7. This product is a solar powered wireless product, so it shall not be installed, tested or operated indoors or in any dark place with a sunlight intensity of less than 2200 lux.
8. This product can trigger an alarm less than 50 times when it is tested under normal sunlight conditions. Never try to test maximum alarm times indoors.
9. Never put the multi-beams light wall in any dark place or cover the solar panel with any material at power-on, otherwise, the product may not be normally powered on.
HB-JHD-2 Solar-power Wireless Warning Lamp
Solar-power Warning Siren Strobe is with built-in sounder and high light lamp. It will illuminate the defense zone and make loud sound when alarm.
It can learn maximum 32 wireless HB brand 433MHz wireless infrared beams, grating and remote controller.
Function:
1. With power on/off button and low illumination sound indication. It will trigger alarm when it is off.
2. Can select alarm sound.
3. Can check power on/off status, device working status and test it.
4. Can use remote controller to arm, disarm, emergency alarm and cancel alarm.
5. It should be installed at place with enough sunlight.
Specification:
1. Working voltage: 6.4V
2. Battery type: LiFePO4 battery
3. Battery capacity: 3000mAH
4. Static working rate current: 2mA
5. Wireless receiving distance: 300m at open area
6. Working environment temperature:-30℃~70℃
7. Alarm Volume: 90dB
8. High light LED luminous flux: 70 lm each
9. Dimension: 280*180*74mm
Solar Siren strobe operation steps:
Total 4 buttons(On/Off Key;Learning Key;Delete Key;Choose Sound Key)
How to connect detectors and remote controllers
1. Press the On/Off Key 3-10 times to turn on the siren.
(if work normally, there are 3-6 “di” beep prompt)
【Notice1】if press the On/Off Key 3 times to turn on,the siren will alarm 5 seconds while sensors
be triggered; if 4 times,the siren will alarm 15 seconds;if 5 times,the siren will alarm 30 seconds;if 6 times,the siren will alarm 60 seconds;if 7-10 times,no alarm voice.
【Notice2】If there are 3”di~~”long beep prompt while you turn on the siren,it means the siren is Low battery or the solar panel was covered by thick materials;
All the setting will take effect after 1 hour,within 1 hour,the siren will alarm 5 seconds while sensors be triggered.
2. Press the”Learning Key” once,”Learning Key”light on and a beep prompt
(means the siren is on Learning mode)
3. Trigger the sensor or press the arm key of remote controller,”Learning Key”light off and a beep prompt( connect successfully)
4. Connect other sensors or remote controllers by the same way
(press “Learning Key”once,trigger the sensor)
How to delete sensors and remote controllers
1. Turn on the Siren.
2. Delete one sensor(the recent one)--Press”Delete Key”once,and”Delete Key”light on 1 second and a beep prompt.
Delete all the sensors--Press”Delete Key”3 seconds,”Delete Key”light on and a long beep Prompt.
How to choose the alarm voice(total 2 sounds,one is doorbell,one is Alarm)
1. Turn on the siren
2. Press the”Choose Sound Key”once,the sound you heard is the one you choose.
【Notice】The operations of Learning,Deleting,Choosing Sound must be operated within 1 hours after turn on the siren.if after 1 hour,you should restart the siren to operate.
