Driveway Intrusion Alert Security System Solar Beams Detection

  • Model: HB-T001+Siren
  • Shipping Weight: 5.5 kgs
  • 494 Units in Stock
  • Manufactured by: HB solar beams

 Ask a Question


Add to Cart:
Outdoor Siren strobe for alert of driveway intrusion detection system.
The package is used for house or business perimeter security.
It is newest technology wireless solar powered beams system and solar-powered siren strobe.
Leading package includes 1x 3 beams with LCD calibrator solar-powered infrared detector and 1 pc siren strobe solar-powered outdoor installation with 2 pcs remote controller.
One siren strobe can equip with maximum 32 wireless beams and remote controllers.
Details of driveway intrusion alert neighbor and police notice security system
Wireless beams detector updated with LCD calibrator and electricy power supply and battery rechargeable power jack. Infrared Distance 120m, Wireless emitting distance 1km
Contact us if you have any question. Shopping guide at how to shop alarm
Specification of the solar powered wireless beams detector:
Infrared Distance: 120m
Wireless Transmitting Distance: 800m
Wireless Transmitting Frequency: FM: 433MHz
Maximum alarm times in 24 hours: Not more than 50times.
Battery Capacity: 500mAh (Transmitting terminal), 1000mAh (Receiving Terminal)
Working environment temperature range: -30C~70C
Number of infrared beams: 3 beams
Operating Voltage: 3.3V
Static Operating Current: Transmitting terminal<=0.5mA, Receiving terminal<=0.5mA
Infrared light frequency: Secondary moudulation & encoding based on 38KHz
Infrared Light wavelength: 940nm+/-20nm
Solar electric panel output current: >=2mA at light intensity of 1800LX (note: the outdoor light intensity in cloudy or rainly days is about 2000LX)
Dimension of product: 340mm*50mm*84mm of Receiving terminal, 340mm*50mm*45mm of transmitting terminal
1.Never install the infrared beams at an inclined angle.
2. Make sure that there is no obstacle between the transmitting terminal and the receiving terminal.
3. Use multiple infrared beams for long distance to avoid mutual interference among beams.
4. Keep the in-frared light hole-posed to direct sunlight.
5. The high-voltage tower and the signal tower may influence wireless transmission distance.
6. Never install this infrared beams near door access systems, passages, areas prone to trigger an alarm or areas which could trigger an alarm more than 50 times per 24 hours.
7. This product is a solar powered wireless product, so it shall not be installed, tested or operated indoors or in any dark place with a sunlight intensity of less than 2200 lux.
8. This product can trigger an alarm less than 50 times when it is tested under normal sunlight conditions. Never try to test maximum alarm times indoors.
9. Never put the multi-beams light wall in any dark place or cover the solar panel with any material at power-on, otherwise, the product may not be normally powered on.

HB-JHD-2 Solar-power Wireless Warning Lamp
Solar-power Warning Siren Strobe is with built-in sounder and high light lamp. It will illuminate the defense zone and make loud sound when alarm.
It can learn maximum 32 wireless HB brand 433MHz wireless infrared beams, grating and remote controller.
1. With power on/off button and low illumination sound indication. It will trigger alarm when it is off.
2. Can select alarm sound.
3. Can check power on/off status, device working status and test it.
4. Can use remote controller to arm, disarm, emergency alarm and cancel alarm.
5. It should be installed at place with enough sunlight.
1. Working voltage: 6.4V
2. Battery type: LiFePO4 battery
3. Battery capacity: 3000mAH
4. Static working rate current: 2mA
5. Wireless receiving distance: 300m at open area
6. Working environment temperature:-30℃~70℃
7. Alarm Volume: 90dB
8. High light LED luminous flux: 70 lm each
9. Dimension: 280*180*74mm
