MD-217R Focus security wireless mini door magnetic contact

  • Model: MD-217R
  • Shipping Weight: 0.1 kgs
  • 1000 Units in Stock
  • Manufactured by: Focus Security

 Ask a Question


Add to Cart:
Fully supervised mini style magnetic contact transmitter. It features door/ window close/open instant alarm function.
It can be connected to the control panel. It can transmit strong wireless signal, having strong intensity in 150m area. Pleas code it to the control panel before using, enrolling the only one address code to the control panel. When the distance between the magnetic stripe and transmitter beyond 1.5cm the transmitter will send alarm information to the panel. This detector can change wired signal to wireless signal.

A. Adopted low consumption CPU
B. Adopted unique Mutil codes
C. Auto status report
D. Anti-lost report
E. Open door/window indication

Wireless sending distance(open area):inset antenna 150m.
Code: 28-digi t ID, 8-digit function code, 36 digits data code in total
Working frequency: 433MHz/868MHz(optional)
Working voltage:3V CR2032
Battery life: about 1 year
Current: static ≤5uA, alarm≤7-12mA(433MHz), static ≤5uA, alarm≤15-25mA (868MHz)
Alarm output: alarm, tamper
Status report:after fist electro motion or reset the
detector the magnetic switch report the working status
to the control panel separately after 1 minutes,6minutes.
And report working status every two hours to the
control panel.
Working Temeprature:-10℃~50℃
